AutoMount 103827B - Semi Automatic Swing Arm Tyre Changer for Motorcycle, Car, 4WD & Commercial Tyres

Ideal usage: Automotive Workshops

European designed with quality engineered gearbox and European reversing switch, this swing arm semi-automatic tyre changer is ideal for the easy removal of car, 4WD & light commercial tyres, as well as motorcycles tyres with the optional motorcycle adaptor. An entry level tyre changer, coupled with high quality, durable European manufactured components makes this an affordable solution for mid range tyre & mechanical repair workshops.

Outer Clamp 10 - 20"
Inner Clamp 12 - 23"
Air Supply: 8-10 Bar

• Large bread breaking cylinder
• Improved design and technology
• Large square turn plate with 584mm (23”) internal wheel clamping.
• No adapters needed – motorcycle adaptors available (optional extra)
• Reversible turn plate
• Tilting column and pneumatic locking system
• Inflation Gauge
• Single speed reversing switch
• Adjustable bead breaker blade

• External rim clamping 10”-20” (254-508mm)
• Internal rim clamping: (305-584mm)
• Maximum tyre diameter: 49” (1245mm)
• Break breaker tyre width capacity: 3”-15” (76-381mm)
• Power supply: 240V/ 50Hz / 1 Phase
• Air supply: 8-10 Bar
• Motor power: 0.75KW-1.1KW
• Noise level: <75dB
• Packing Size: 1200mm x 920mm x 1050mm
• Net weight: 230 Kg
